KAB 525
KAB 525 - Image 2

KAB 525

Contact us for a price

The KAB 525 is a sturdy mid backed mechanical seat suitable for a lot of medium-large machinery such as Terex and Franna cranes, large forklifts, loaders, dozers and more.  Featuring all the standard adjustments and optional extras you’d expect.

SKU: KA-KSS5250FWC Categories: , , , Brand:

Product Description

The KAB 525 is a sturdy mid backed mechanical seat suitable for a lot of medium-large machinery such as Terex and Franna cranes, large forklifts, loaders, dozers and more.

Featuring adjustable air lumbar, back angle, weight from 80 – 150kg, seat height and tilt and slide rails.  A choice of forward, right hand or left hand mounted controls and 280 slide rail width makes this seat suitable for a range of different fit ups.  Optional armrests, headrest, turntable and lap belt available.

Features

Brand
Brand

KAB
Suspension Type
(Suspension Type) Model

KAB 52
(Suspension Type) Type

Mechanical – Large
Suspension Features
(SF) Fore/Aft Adjust Lock

Double
(SF) Fore/Aft Adjustment

200mm
(SF) Height Adjust Range

60mm
(SF) Shock Absorber

Fixed
(SF) Slide Rail Width

280mm
(SF) Suspension Travel

100mm
(SF) Swivel

Optional
(SF) Weight Adjustment

80-150kg
Seat Top Features
(STF) Arm Rest

Optional
(STF) Back Height

Mid 400-550mm
(STF) Back Tilt

Yes
(STF) Base Tilt

Yes
(STF) Base Width

Std 450-499mm
(STF) Headrest

Optional
(STF) Lap Belt

Optional
(STF) Model

KAB T5
(STF) Trim

Fabric
